Introducing Feniex Q-Link, the innovative serial device to connect all of your Q Serial lightheads. Specially engineered for use with Feniex’s state-of-the-art serial technology, connect up to 48 Q Serial lightheads using only one Q-Link device. This device is not intended for 3-Mode Q Series products.
Our Q-Link device uses Q Serial Zoning Technology to make programming your build easier than ever before. No need to tap mode wires, simply connect your Q Serial lightheads to your Q-Link device using the 2 serial wires and the Q-Link Software. Then, set each Q Serial lighthead into your desired zones with a touch of the zoning magnet. Within moments, your zones are set and you can program any function and color using our intuitive Q-Link Software.
Feniex Q Link Module
- Current Draw: 1 Amp
- Cable Length: 1 Foot
- LED Count: 27 LEDs
- Input Voltage: 10-18VDC
- Dim: 5.25" x 0.88" x 1.17"
- 5 Year Manufacturer Warranty
- Made in the USA: Austin, TX
- Zoning magnet included
- 27 programmable inputs
- Includes 8 serial ports
- Each serial port supports up to 6 Q Serial lightheads
- Syncs up to 48 lightheads using one Q Link device
- Comes with unlimited use of Feniex’s Q Link Software
- Over 20 programmable flash patterns
- Available functions include Flood, Cruise, and Stop Tail Turn and more
- SAE J1113-11 Certified
